Tungsten electrode grinder EG 5, Schweisskraft

For perfect grinding of tungsten electrodes with a diameter of 1.6 to 5 mm.
Grinding angle continuously variable from 0 to 60 degrees.
Stop for setting the correct grinding length integrated in device.
Precise grinding in longitudinal direction for improved ignition properties, stable arc and longer lifetime.
Unproblematic grinding, even down to a length of just 50 mm, spherical tip or drops of metal.
Clamping possible when wearing work gloves via easy-action knurled screw.
Grinding dust easily removable via a drawer.

Technical specifications:
Electrode diameter 1,6 - 5,0mm
Min. electrode length 35mm
Grinding angle 15 – 60°
Speed 6500rpm
Diamond disk diameter 90mm
Length (product) approx. 225mm
Width/depth (product) approx. 150mm
Height (product) approx. 195mm
Net weight approx. 4.1kg
Drive motor output 0.07kW
Supply voltage 230V

Scope of delivery:
Diamond disc Ų 90 mm
One collet each 1,6 / 2,0 / 2,4 / 3,2 / 4,0 mm.
