Engine: Kubota 3 cylinder liquid cooled diesel engine
Total displacement (engine capacity): 1261 cm³
Horsepower: 26 hp (19,1 kw)
Fuel tank capacity: 27 l
Gearbox: hydrostatic (HST), hydrostatic powersteering, 3 geargroups, differential locking
Driveline: 4 wheel drive (4 WD), Bi-speed turning function (turning radius 2,1 m)
Travelling speed: 25 km/h
Hydraulics: hydraulic pump capacity 33,1 l/min, hydraulic outlets in front and rear
Rear linkage: Cat 1, 970 kg lifting power
PTO: rear PTO 540 rpm, mid PTO 2500 rpm
Mid mowerdeck width: 3 blades, 152 cm side discharge (additional equipment)
Front loader: LA424 with lifting power 420 kg, lifting height 1914 mm (additional equipment)
Front linkage: lifting power 600 kg (additional equipment)
Front PTO: 1000 rpm (additional equipment)
Collector system: 850 L hydraulically lifted up to 2,15 m (additional equipment)
Cabin: air condition, good visibility
Tyres (front/rear): 24 x 8,50 - 12 / 315/75D - 15
Dimensions (length x width x heigth): 2887mm x 1304mm x 2136mm
Extras: digital display panel, hand throttle, adjustable steering wheel angle
Weight: 1015 kg
Street legal
Warranty: 2 years or 1500 h All pictures and videos are illustrative.
