Cooling pad, dm³: 80
Air flow, m³/h: 12,000
Maximum area, m²: 250
Power consumption, W: 500
Power supply, V/Hz: 220-240/1ph/50
Rated current, A: 2.7
Water consumption, l/h: 8-10
Tank capacity, l: 60
Direct water connection, inch: ½
Tank level control: Yes
Product size (l x w x h), mm: 1050 x 600 x 1460
Box size (l x w x h), mm: 1120 x 680 x 1640
Net/gross weight, kg: 50/55
Efficient and durable spot cooler for industrial applications
Quiet running even with large air-flow
Automatic swing function as standard
Large water tank for longer operating hours
Large, durable wheels with brakes allow easy movement
Connect water hose or refill tank manually to offer comfort to your employees
Corrosion-resistant plastic casing
Air filter included to enable easy maintenance
Remote control to easily adjust speed
UV lamp, disinfecting the water
The heart of the evaporative cooling system is the cooling pad where the water evaporates and the air passing through the pads is cooled. Evaporative cooling pads are manufactured from fluted cellulose sheets that are glued together. The material is chemically impregnated with special compounds to prevent rot and ensure a long service life and easy maintenance.
A given volume of air at a certain temperature and pressure is capable of absorbing and holding a certain amount of water vapour. If that volume of air contains 50% of the moisture it is capable of holding, we say it is at 50% relative humidity.
The hotter the day, the drier the air, the more cooling can be done by means of evaporation. In other words, the cooling effect is best when you need it most.
Our evaporative coolers are developed to work well in high-humidity environments too, however, and will remain much more efficient than a simple fan that just circulates warm air.
Our coolers will increase humidity by 2 to 5%, depending on temperature and humidity in the environment you want to cool. The slight increase is not noticeable in ventilated areas where the air produced by the unit is exhausted.
All pictures and videos are illustrative.
