Plasma cutting - anywhere, anytime.
The Tomahawk® 30K plasma cutter is ready for fast and accurate cutting - it works both with a built-in compressor and when connected to a compressed air line. Forget the angle grinder, just pick up the torch and cut in seconds.
Maximum cutting power 16mm (recommended up to 12mm).
Functions:
• Ultimate portability – the internal air compressor enables operation in environments where external compressed air is not available.
• Continuous output control – suitable arc for different material thicknesses.
• "Touch Start" starting system - reliable plasma arc starting without high frequency.
• Rapid Arc Restrike - rapid cutting of gaps.
• Pressure regulator on the front panel - makes it easy to set the air flow rate without starting the plasma arc.
• Dip and grid modes (adjustable grid time)
• New design of electrodes and nozzles save money in the long run.
• Additional safety – our consumables installation system detects correct installation of consumables and torch.
• Select a suitable generator to power the Tomahawk® in remote locations.
Technical specifications:
Supply voltage 230V, 1-phase,
Current strength 15-30A.
Protection (slow) 16A. 20A when starting the arc.
Duty cycle 30A@60%, 25A@100%.
Weight 18.5 kg.
Dimensions 385x215x480mm.
Air requirement 125l/min +/- 10% @ 5.0-6.0bar.
The set includes:
Built-in air compressor, power cable, 4m manual torch LC30, ground clamp and cable, consumable parts for the torch, built-in moisture separator.
2-year warranty.
All pictures and videos are illustrative.
