Load-bearing capacity 1.5t
Load-bearing width 540mm
Fork width 160mm
Fork length 1150mm
Lifting range 80 - 195mm
Lifting speed 0.015m/s
Lowering speed 0.05m/s
Travel speed 4.9km/h
Turning radius 1340mm
Steering rollers material Polyurethan
Load rollers material Polyurethan
Max. grade ability loaded 6%
Max. grade ability unloaded 16%
Steering rollers diameter 210mm
Steering rollers width 75mm
Load rollers diameter 80mm
Load rollers width 70mm
Power drive motor 0.75kW
Lifting motor output 0.5kW
Battery voltage 24V
Battery capacity 20Ah
Net weight approx. 136kg
All pictures and videos are illustrative.
