- Easy adjustments in the field with minimal maintenance and reduction of the costs
- Machine is designed and tested following highest farmer’s requirements in terms of performance and reliability
- Can be equipped with different blade types in order to fulfill all operating conditions
- Five V-belts with an automatic belt tensioner ensure smooth power transmission and no maintenance required
- High rotor clearance for better performances in tough conditions
- The wide diameter of the rotor (650mm) guarantee an excellence cut with lower power requirement
- Rotor with 2 rows self adjustable spherical bearings
Non-offset chopper for agri purposes
For tractors 55-160 hp
Heavy construction for a reliable utilization
Special skids profile avoid bulldozer effect on land stubble
Optional rear roller or wheels
For tractors 55-160 hp
Heavy construction for a reliable utilization
Special skids profile avoid bulldozer effect on land stubble
Optional rear roller or wheels
Working width:2,8 m
Transport width:3,02 m
PTO:540/1000 rpm
Power requirement:55-160 hp
Universal blades:72
Hammer blades:36
Rear roller diam.:245 mm (optional)
For rear use, CAT2
Universal blades
Recommended power requirement: 55-160 hp
Working width 2,8 m
Transport width 3,02 m
Weight 1174 kg
PTO speed 540/1000 p/min
No of transmission belts 5, V-belts, automatic tensioning, maintenance free
Universal blades 72 pcs, available also hammer blades 36 pcs
Blade distance 75 mm
Rotor 245 x 10 mm
Cutting diameter 651 mm
Rotor speed 1844-1949 p/min
Blade tip speed 63-66 m/s
Rear roller diam 245 mm (optional, not included in price) - suggested for irregular fields and generally dry working conditions
2 pivoting wheels (155 SR13-optional, included in price) - suggested for wet conditions giving perfect maneuverability
Skids
Manufactured in Italy
Warranty 2 years
Pictures are illustrative and for non-contractual use
