- Excellent performance as well as very limited power requirement and maintenance activities
- High chopping chamber guarantees blockage free performance in even the toughest conditions
- The roller bearings are integrated and protected and do not need regular greasing
No offset, for agri purposes
Compact heavy duty machine
For tractors 65 - 110 hp
Solid construction for long life and minimal maintenance
The standard skids
Optional support wheels or rear roller
Compact heavy duty machine
For tractors 65 - 110 hp
Solid construction for long life and minimal maintenance
The standard skids
Optional support wheels or rear roller
Working width:2,8 m
Transport width:3,0 m
PTO:540/1000 rpm
Power requirement:65-110 hp
Universal blades:68
Hammer blades:34
Rear roller diam.:245 mm (optional)
For rear use, CAT2
Hammer blades
Recommended power requirement: 65-110 hp
Working width 2,8 m
Transport width 3,0 m
Weight 940kg
PTO speed 540/1000 p/min
No of transmission belts 5, V-belts, screw tensioning
Hammer blades 34 pcs, available also universal blades 68 pcs
Blade distance 75 mm
Rotor 194 x 10 mm
Cutting diameter 600 mm
Rotor speed 1789-1887 p/min
Blade tip speed 56-59 m/s
Rear roller diam 245 mm (optional, included in price) - suggested for irregular fields and generally dry working conditions
2 pivoting wheels (155 SR13-optional, not included in price) - suggested for wet conditions giving perfect maneuverability
Skids
The rear cover can be opened due to perform in fields with large amounts of crop residue.
Manufactured in Italy
Warranty 2 years
Pictures are illustrative and for non-contractual use
