- Wide choice of blades and sideways adjustment to maneuver around or under trees and bushes
Offset chopper
Compact heavy duty machine
For tractors 50 - 66 hp
Solid construction for long life and minimal maintenance
The standard roller and the skids support the chopper and provide a regular working height
Compact heavy duty machine
For tractors 50 - 66 hp
Solid construction for long life and minimal maintenance
The standard roller and the skids support the chopper and provide a regular working height
Working width
2,0 m
Transport width
2,22 m
PTO
540 rpm
Power requirement
35-80 hp
Universal blades
52
Hammer blades
26
Offset
500 mm
Rear roller diam.
160 mm
Offset chopper
Recommended power requirement: 50-66 hj
Working width 2,0 m
Transport width 2,22 m
Weight 572 kg
PTO speed 540 rpm, freewheel clutch
Transmission belts 5, V-belts, automatic tensioning, maintenance free
Hammer blades 26 pcs, available also universal blades 52 pcs
Blade distance 75 mm
Rotor 169 x 10 mm
Rotori shaft diam 50 mm
Cutting diam 452 mm
Rotor speed 2160 rpm
Blade tip speed 51 m/s
Offset 500 mm
Rear roller diam 160 mm
Skids
Double skin 4mm
Manufactured in Italy
Warranty 2 years
Pictures are illustrative and for non-contractual use
