This KONFORT 760R model is equipped with a high resolution color TFT display. All station functions are fully automated.
Lockable scales for transport. Fully sealed oil and paint tanks.
Technical data
* Agent (freon): R1234yf
* Service procedures Automatic or manual
* Power supply: 220-240V / 50 Hz
* Freon weighing accuracy: ± 5 g
* Weighing accuracy of oil and UV paint ± 1 g
* Ambient temperature measurement ± 1 °C
* Tilt sensor (on 3 axes) 1°
* Operating temperature: 5 - 49 ° C
* Two-stage vacuum pump: 100 Ltr / min
* Compressor: 12cc
* Freon capacity: 20 kg, refillable
* Hose length: 3 meters
* Dimensions: 1195 x 598 x 749 mm
* Weight: 98 kg
* Printer not available (optional)
* 2 GB memory (SD card)
* Manometer accuracy class 1
* Screen TFT 320x240, 65,000 colors
* Integrated database
* Freon extraction efficiency - 95% (according to SAE J2788 and SAE J2843)
* 24 months Manufacturer's warranty
* Training for working with the device
SOME KEY FEATURES:
* Suitable for R134a or R1234yf freon
* High resolution TFT color screen
* Database recovery and data transfer with SD card
* Rotatable screen with gauges
* 20 kg internal freon capacity
* Two-stage vacuum pump
* High freon extraction efficiency (up to 95%)
* Hermetic containers for grease and paint
* Very accurate automatic oil dosing
* Weight locking mechanism for transporting the station
* Automatic discharge of non-condensing gas
* The device is compatible with a hybrid car
* Protection against ignition
* Tilt sensor
* Freon analysis kit
* Thermal printer (must be purchased separately)
All pictures and videos are illustrative.
