Product info
Max. wheel diameter 46" | 1170mm
Bead breaker force 2800 N
Operating pressure 8 - 12 bar
Max. wheel width 15" | 381mm
Length 1450 mm
Height 1900 mm
Width 1030 mm
Power supply 400V | 3Ph | 50-60Hz
Motor power 1,5 kW
Max. clamping capacity 27 "
Max. torque 1200 Nm
Space requirement width 1450 mm
Space requirement length 1850 mm
Rotation speed 8 | 16 rpm
Packaging length 1050 mm
Packaging width 1260 mm
Packaging height 2100 mm
Min. clamping capacity 10 "
Number of mounting speeds 2
Clamping device design Clamping plate
Min. inner clamping range 12 "
Max. inner clamping range 27 "
Min. outer clamping range 10 "
Max. outer clamping range 24 "
Mounting head design With tire lever
Mounting arm design Moveable
Mounting column design Tiltable
Bead breaker cylinder force 25000N @ 10bar
Beda breaker force on shovel 13000N @ 10bar
Tyre inflation Foot control
Turntable height 670 mm
Bead breaker operation Manual control
- Weight 343 kg
- Weight with package 686 kg
- Dimensions (with package) 120 x 100 x 100 cm
- Sales unit pcs
- GTIN / EAN 1692401004
- Manufacturer part number 1692401004
