Product info
Feeding speed of workpiece 3m/min
Bevel dimension (diagonal) 0 ÷ 18mm
Bevel angle 22,5 - 30 - 37,5 - 45 -52,5°
Workpiece thickness allowed 5 ÷ 60mm
Workpiece diameter allowed 110mm
Milling cutter diameter 93mm
Workpiece width allowed 80mm
Workpiece length allowed 200mm
Motor 1,1kW/400V
Motor speed 1400rpm
Acoustic emission 70dB
Overall dimension (Width x Depth x Height) 350 x 615x H. 690mm
Weight standard machine 150kg
Complete of Nr.1 milling cutter for bevelling of iron steel (code 002840_FR1)
