Product info
GENERAL SPECIFICATIONS
RangeDIESEL
Frequency (Hz)50 Hz
Max power LTP (kW)5.20
Max power LTP (kVA)6.50
Nominal voltage (V)400
Number of PhaseThree phase
FuelFuel
Tank (L)27
75% cons. (l/h)1.20
75% Autonomy (h)22.50
Sound power level guaranteed LwA dB(A)92
Acoustic pressure level @1m in dB(A)76
Acoustic pressure level @7m in dB(A)63
ENGINE SPECIFICATIONS
Engine brandKOHLER DIESEL
Engine ref.KD15-440E
DistributionDiesel O.H.V.
StartElectrical
Low Oil pressure shutdownOui
Displacement (cm3)442
Oil capacity (L)1.50
ALTERNATOR SPECIFICATIONS
TechnologyWithout collar or brush
AVR RegulationYes
Indication of protectionIP 23
Insulation classH
PLUGS AND PANEL DESCRIPTIVE
1 230V 10/16A socket - circuit breaker + 1 230V 16A socket - circuit breaker + 1 400V 16A socket - circuit breaker + hour meter + indicator + APM202
DIMENSIONS AND WEIGHT
Lenght (cm)99 (101)
Width (cm)61.50 (63)
Height (cm)96 (98)
Dry Weight (kg)215.50
PRODUCT ADVANTAGES
Entire group guaranteed 3 years
KOHLER air-cooled industrial engine
Very Silent
Connection interface equipped with an hour meter
Hydrocarbons bulk tank
ACCESSORIES SUPPLIED
User and maintenance manual
Battery without maintenance
Lifting eye
Hour meter
